扁平按钮设计提升接触稳定性 (Flat button design enhances contact stability)
不同高度和力度可供选择 (Various heights and force levels available)
能源/工业: 工业设备 (Industrial Equipment)
家用: 办公设备 (Office Equipment)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -30℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA 16V DC |
| 绝缘电阻 Insulation resistance | 100MΩmin.100V DC for 1 min | |
| 介电强度 Dielectric strength | 250V AC for 1 min. | |
| 接触电阻 Contact resistance | 100mΩ max. | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 Cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | J:160gf C:250gf |
| 行程 Travel | 0.30 ± 0.10 mm | |
