Smaller size makes better heat convection during PC board wave soldering;
Top tape sealed to withstand wave soldering,board washing;
All plastics are UL 94V-0 grade fire retardant;
Gold plated contact to ensure low contact resistance and long mechanical life.
Hand-held electronic devices, such as PDA,MP3,radios;
Portable computer and electronic devices,such as notebook,computers;
Instrumentation and industrial control products,such as CDROM, coin changers
| Items | Standard | |
|---|---|---|
| Environmental | Operating temperature range | -20℃ to +85℃ |
| Storage Temperature Range | -40℃ to +85℃ | |
| Electrical performance | Electrical Life | 2,000 cycles |
| Switching Rating | 25mA, 24VDC | |
| Mechanical performance | Operating force | 1,000gf |
| Travel | 1.0mm | |
| Package | Tube | DEH(R)-01:194pcs/tube DEH(R)-02:95pcs/tube DEH(R)-03:63pcs/tube DEH(R)-04:47pcs/tube DEH(R)-05:38pcs/tube DEH(R)-06:31pcs/tube DEH(R)-07:27pcs/tube DEH(R)-08:23pcs/tube DEH(R)-09:21pcs/tube DEH(R)-10:19pcs/tube DEH(R)-12:15pcs/tube |
