| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +70℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 100mA. 42V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. DC 100V | |
| 介电强度 Dielectric strength | AC 250V for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 10×10⁵ cycles |
| 机械性能 Mechanical performance | 操作力 Operating force | 330±80gf |
| 行程 Travel | 0.34±0.2mm | |
