清晰的按键点击感和正向触觉反馈 (Sharp click feel with a positive tactile feedback)
超小型轻量化结构，适合高密度安装，经济实惠且可靠 (Ultraminiature and light weight structure suitable for high density mounting, Economical but reliable)
接点采用特殊处理的插入成型设计，可防止焊接时助焊剂堆积，并支持自动浸焊工艺 (Insert molding in the contact with special treatment prevents flux build-up during soldering and permits auto-dipping)
可用于操作各种多功能电子设备，例如相机、数码相机、数码摄像机、小型便携设备等。
Can be used to operate various multifunctional electronic devices, such as cameras, digital cameras, digital camcorders, and small portable devices etc.
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -20℃ to +70℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 100mA. 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. DC 100V | |
| 介电强度 Dielectric strength | AC 250V for 1 min | |
| 接触电阻 Contact resistance | 100mΩ max | |
| 耐用性 Durability | 寿命 Lifetime | 2×10⁴ cycles |
| 机械性能 Mechanical performance | 操作力 Operating force | 1st: 110±30gf 2nd: 270±50gf |
| 行程 Travel | 1st: 0.35±0.15mm 2nd: 0.15±0.1mm | |
