超小型、侧按 (Ultra-compact, side button)
沉板式安装设计 (Recessed mounting design)
M智能手机, 平板电脑, 头戴式耳机, 可穿戴设备, 笔记本电脑及周边 (Smartphones, Tablets, Headphones, Wearables, Laptops & Peripherals)
便携式电子设备 (Portable Electronic Devices)
3C产品 (3C Products)
| 项目 Items | 参数 Standard | |
|---|---|---|
| 工作温度范围 Operating temperature range | -40℃ to +85℃ | |
| 电气性能 Electrical performance | 额定电流 Rating | 50mA. 12V DC |
| 绝缘电阻 Insulation resistance | 100MΩ min. 100V DC | |
| 介电强度 Dielectric strength | 250V AC for 1 min. | |
| 接触电阻 Contact resistance | 100mΩ max. | |
| 耐用性 Durability | 寿命 Lifetime | 100,000 Cycles |
| 机械性能 Mechanical performance | 动作力 Actuating Force | 160 ± 40 gf |
| 行程 Travel | 0.15 ± 0.05 mm | |
